Whelen L22 Super LED Encapsulated Beacon

L22 Series is a certified SAE Class II LED warning beacon with SignalAlert™ and 14 other effective flash patterns. L22 models feature generation 3.5 LED technology that rivals strobe in power with lower amp draw. LED light source has a rated life that exceeds that of comparable flash tubes by more than 50:1.

FEATURES

• Certified SAE Class J845 Class II 360° (amber)
• 100,000 hour rated life
• Low current draw: 0.65 amp (peak), 0.26 amp (avg.) @ 12.8 VDC
• Combination mounting (pipe/perm/J-hook) allows universal application
• SmartLED® beacon design features 75 SignalAlert™ flashes per minute standard; 14 additional Scan-Lock™ flash patterns built-in
• Supplied with 6" pigtail (combination mount) or 10' straight cord with LED indicator switch and cigar plug (magnetic mount)
• Poly-carbonate base and dome (available high dome only)
• Five year warranty

SPECIFICATIONS

• 12 VDC
• 6-7/16" (163mm) wide at base, 6-13/16" (172mm) high

PERMANENT MOUNT FEATURES

• Combination mounting: 1" pipe/permanent
• Supplied with a 6" pigtail
• 25 Scan-Lock™ alternating and simultaneous flash patterns, including steady-burn
• Synchronize with up to eight Whelen beacons
• Photocell Hi/Low mode available, contact us
• 12 VDC, for 24 VDC models contact us

MAGNETIC/SUCTION MOUNT FEATURES

• Supplied with a 10' cord and cigar plug with built-in On/Off switch with LED "On" indicator and pattern control selection switch
• 80 lb. magnetic mounting base
• 75 SignalAlert™ flashes per minute standard
• 25 Scan-Lock flash patterns
• Low amp draw: 0.65 (peak), 0.26 (average) @12.8 VDC
• 12 VDC
